Logic Circuit
Simulation.
This sketch demonstrates the three basic logic gates, AND, OR and XOR. It also shows the usage of input and output elements. Logic gates are the fundamentals of every logic circuit.
This sketch implements a half adder that is used to add two single binary digits. Half adders can be combined to form full adders, used to add binary numbers.
This sketch implements a full adder that is used to add two single binary digits. Full adders constist of two half adders, taking two binary digits and a carry bit as inputs. Full adders can be combined to build integer adders of any size.
This sketch simulates traffic lights using a 4-bit counter (see example #5) and a diode matrix. There are lights for road traffic and for crossing pedestrians. This example shows the usage of diodes, elements that connect wires in one direction only.
This sketch implements a simple counter made using D gates. It is connected to a clock, permanently increasing the binary output value. When the value passes the biggest possible value (fifteen in this case), the counter restarts from zero.
LogiJS 2 is an open source logic circuit simulator, forked from the original LogiJS.
The motivation for making this fork, was that the original site was missing some features and it was put on hold by it's developer.
If you have any suggestions (new components, or other functianality), feel free to open a new issue on codeberg
